Magnification |
12x |
16x |
Objective lens diameter (mm) |
42 |
42 |
Exit pupil (mm) |
3.5 |
2.62 |
Min. close focus (m) |
4 |
4 |
Field of view (m/1000m) |
67 |
68 |
Field of view (degrees) |
3.85 |
3.9 |
eye relief (mm) |
17 |
14 |
interpupillary distance (mm) |
74-54 |
74-54 |
Height (mm) |
184 |
184 |
max width (mm) |
128 |
128 |
min width folded (mm) |
128 |
128 |
Weight (g) |
720 (no battery) |
735 (no battery) |
Twilight factor |
22.4 |
25.9 |
dioptric compensation (+/-) |
3 |
3 |
waterproof |
IPX7 |
IPX7 |
gas filled |
yes |
yes |
functional temperature |
-20°C / 55°C |
-20°C / 55°C |
light transmisson (%) |
NC |
NC |
warranty (years)* |
30 |
30 |
* warranty electronics (years) |
2 |
2 |
stabilisation correction angle (degrees) |
2 |
2 |
battery life (hours) |
120 (including use of the internal spare battery) |
120 (including use of the internal spare battery) |
angle power control (APC) |
yes |
yes |
sleep timer (minutes) |
yes (90) |
yes (90) |
low battery indicator |
yes |
yes |
batteries (not included) |
2x AA ( + 2xAA spare battery) |
2x AA ( + 2xAA spare battery) |
